GT45 Single Turbo Kit for Ford Mustang 4.6L 2-Valve
Turbo package for 1996-2004 Ford Mustang GT with the 4.6L 2-valve V8. Confirm engine configuration and installation clearances before ordering; compatibility with 4-valve engines is not established by this listing.
Included components
- GT45 turbocharger: T4 exhaust inlet, V-band exhaust outlet, listed 4-inch inlet and 2.5-inch outlet, 98mm compressor exducer, separately listed 107mm compressor air inlet, 88mm turbine inducer, 1.05 turbine A/R and oil cooling. Confirm inlet connection dimensions before selecting couplers.
- Stainless tubular manifolds and T6 pedestal: T4 adapter included, large primaries, thick flanges, V-band clamps and manifold gasket.
- Front-mount intercooler: TIG-welded aluminum construction.
- Manual boost controller: CNC-machined anodized aluminum with installation kit.
- Universal aluminum intercooler piping kit: 16 stainless worm-gear clamps; two 2.5-inch 90-degree silicone couplers; six 2.5-inch straight couplers; two each of 2.5-inch 90-, 60- and 45-degree bends; two straight 2.5-inch pipes. Modification may be required.
- Turbo oiling kit: oil feed and return lines, fittings, clamps, gaskets and hardware. Listed return-line pressure rating: 550 PSI.
- Aluminum battery relocation kit: cables, straps and hardware.
- Slim cooling fan: reversible push/pull design with mounting tabs; listed thicknesses of 1.25 inches at the outer perimeter and 2.50 inches at the inner perimeter.
- Electronic turbo timer: LED display and wiring.
- Adjustable fuel pressure regulator: pressure gauge and installation kit, plus 6AN billet aluminum inline fuel filter.
- Stainless crossover: polished finish and flex section; pedestal includes a 60mm wastegate flange.
- Oil catch can: polished finish and installation kit.
- Blow-off valve: installation kit included.
- Stainless exhaust pipe kit: polished pipe, 2-bolt flange and turndown.
- Coolant bung: 38mm anodized blue aluminum.
- Heat wrap: 50-foot roll, 1 inch wide.
- 60mm external wastegate: gasket, installation hardware and extra springs; atmospheric venting configuration.
- 4-inch cone air filter: washable.
- Boost gauge: 52mm white-face gauge with bracket and instructions.
Installation and safety
Professional installation, appropriate fueling, engine management and custom tuning are required. Additional adapters or fabrication may be needed. Confirm accessory clearances; retention of air conditioning and power steering is not guaranteed. Horsepower output and safe boost levels depend on the engine and supporting modifications; no stock-engine boost setting is guaranteed safe. Verify emissions requirements before public-road use. Route hot exhaust and wastegate discharge safely away from wiring, hoses and other components.
